Twin cable gland, metric thread, light grey M 20 x 1,5

Twin cable gland, metric thread, light grey

Item no. 2024063 | EAN 4012195088639

Item no. / Types	2024063 / 113 M20 LGR

Thread	M 20 x 1,5

Product description

Product description

IP54 protection rating, with removable polystyrene lid, as well as two connection thread sealing rings made of polyethylene.

With connection thread M20 x 1.5, 2 half glands PG 13.5 for cable diameter 6.5–10.5 mm.
113/M20: with connection thread M20 x 1.5, 2 half glands Pg 13.5 for cable diameter 6.5–10.5 mm.

Technical data

Technical data

Bend protection	no
Colour	Light grey; RAL 7035
Dimension	M20
explosion-proof	no
Fibre-glass reinforced	no
Flame-resistant	acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
Flat cable gland	no
For Ex zone	Without
Halogen-free	yes
Impact-resistant	no
Material	Duroplast, Aminoplast

Protection rating	IP54
Sealing area D, max.	10,5 mm
Sealing area D, min.	6,5 mm
Sealing insert, multiple	no
Splittable gland	no
Strain relief option	no
Thread	M 20 x 1,5
Thread type	Metric
Version for	Straight
With locknut	no
