Trunking end piece, height 40−240 mm 400 | 40 | 240
morepic-1 morepic-2

Trunking end piece, height 40−240 mm

Item no. 7424304 | EAN 4012195243908

40 mm
240 mm
Product description

Product description

Ready-to-mount trunking end piece, consisting of a flexible apron with side and floor covering guide profiles. The scope of delivery contains trunking connection brackets and a height-adjustable fixing bracket.
  • Verband der Elektrotechnik, Elektronik, Informationstechnik e.V., Germany
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Duct height, min. 40 mm
Height-adjustment range, max. 200 mm
Material Steel
Suitable for flushfloor, open underfloor trunking yes
Suitable for screed-covered underfloor ducts no
Suitable for screed-flush closed underfloor ducts no
Surface Strip galvanized
Trunking height, max. 240 mm

Dimensions

Dimension h 40 mm
Length 460 mm
Width 400 mm
All types

All types

Types Width Duct height, min. Trunking height, max. Item no. Quantity SSU
OKA-G20040240ES 200 mm 40 mm 240 mm 7424300
1 piece
OKA-G30040240ES 300 mm 40 mm 240 mm 7424302
1 piece
OKA-G40040240ES 400 mm 40 mm 240 mm 7424304
1 piece
OKA-G50040240ES 500 mm 40 mm 240 mm 7424306
1 piece
OKA-G60040240ES 600 mm 40 mm 240 mm 7424308
1 piece
Downloads

Download

Download

Download

Download

Download

No invitation to tender text is available for this product.
