Fastening type	Screw hole
Halogen-free	yes
Material	Polystyrene
Number of cables/pipes	1
Plastic-covered	no
Size	Pg 9
Suitable in fire protection area	no
Thread	M6
UV-resistant	no
Version for	Closed

Types	Clamping range D, min.	Clamping range D, max.	Colour	Item no.	Quantity	SSU
2960 11 M6 LGR	9 mm	11 mm	Light grey; RAL 7035	2130114	piece	50 piece
2960 12 M6 LGR	12 mm	13 mm	Light grey; RAL 7035	2130122	piece	50 piece
2960 15 M6 LGR	15 mm	17 mm	Light grey; RAL 7035	2130157	piece	50 piece
2960 18 M6 LGR	16.5 mm	18 mm	Light grey; RAL 7035	2130181	piece	50 piece
2960 22 M6 LGR	20.5 mm	22 mm	Light grey; RAL 7035	2130211	piece	50 piece
2960 25 M6 LGR	22.5 mm	25 mm	Light grey; RAL 7035	2130254	piece	25 piece
2960 28 M6 LGR	25.5 mm	28 mm	Light grey; RAL 7035	2130289	piece	25 piece
2960 35 M6 LGR	31.5 mm	35 mm	Light grey; RAL 7035	2130351	piece	25 piece
2960 40 M6 LGR	36.5 mm	40 mm	Light grey; RAL 7035	2130408	piece	20 piece
2960 43 M6 LGR	40.5 mm	43 mm	Light grey; RAL 7035	2130432	piece	20 piece
2960 47 M6 LGR	45.5 mm	47 mm	Light grey; RAL 7035	2130475	piece	15 piece
2960 54 M6 LGR	50.5 mm	54 mm	Light grey; RAL 7035	2130548	piece	15 piece

ISO base clip

Product description
