Cover with turn buckle A2 3000 | 300 | 1.5

Cover with turn buckle A2

Item no. 6227362 | EAN 4012195751304

Item no. / Types

Length	3000 mm

Width

Plate thickness	1.5 mm

Product description

Product description

Cover for wide span trays and ladders with the side height 110 and 160 mm.
Take appropriate constructive protection measures if there are high wind speeds.

Technical data

Technical data

Colour	stainless steel
Dimension	300x3000
Dimension B	300 mm
Dimension H	15 mm
Dimension L	3000 mm
Fastening type	Sash lock
Height	13 mm
Length	3000 mm
Maintain electrical functions	no

Material	Stainless steel
Number of turn buckles	6 St.
Plate thickness	1,5 mm
Rustproof steel, pickled	no
Suitable for cable ladder	yes
Suitable for cable tray	yes
Suitable for mesh cable tray	no
Surface	Bright, treated
Width	300 mm

All types

All types

Types	Length	Width	Plate thickness	Item no.	Quantity	SSU
WDRL 1116 20 A2	3000 mm	200 mm	1.5 mm	6227360	m	3 m
WDRL 1116 30 A2	3000 mm	300 mm	1.5 mm	6227362	m	3 m
WDRL 1116 40 A2	3000 mm	400 mm	1.5 mm	6227364	m	3 m
WDRL 1116 50 A2	3000 mm	500 mm	1.5 mm	6227366	m	3 m
WDRL 1116 60 A2	3000 mm	600 mm	1.5 mm	6227368	m	3 m
