Cover for 90° vertical bend 85, falling, FS 500 | 0.75
morepic-1 morepic-2 video-1

Cover for 90° vertical bend 85, falling, FS

Item no. 7131006 | EAN 4012195712022

0.75 mm
Product description

Product description

Cover for falling vertical bends of side height 85 mm.
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Bend (angle) 90°
Change of direction Vertical, falling
Dimension B500mm
Dimension B 500 mm
Fastening type Sash lock
Height 85 mm
Hinged no
Maintain electrical functions no
Material Steel
Plate thickness 0,75 mm
Plate thickness 0,03 in
Rustproof steel, pickled no
Suitable for cable ladder no
Suitable for cable tray yes
Suitable for mesh cable tray no
Surface Strip galvanized
Width 20 in
Width 500 mm
All types

All types

Types Width Plate thickness Item no. Quantity SSU
DBV 85 100 F FS 100 mm 0.75 mm 7130990
1 piece
DBV 85 200 F FS 200 mm 0.75 mm 7130994
1 piece
DBV 85 300 F FS 300 mm 0.75 mm 7130998
1 piece
DBV 85 400 F FS 400 mm 0.75 mm 7131002
1 piece
DBV 85 500 F FS 500 mm 0.75 mm 7131006
1 piece
DBV 85 600 F FS 600 mm 0.75 mm 7131010
1 piece
