Cable tie, black, UV and weather-resistant

Item no. / Types

Length

Max. Bundle diameter

Colour	Black

Product description

Product description

Cable ties are used for quick, uncomplicated fixing or bundling of cables and pipes to cable support systems or other mounting structures.

Technical data

Colour	Black
Dimension	2,5x200mm
Fastening type	Without
Halogen-free	yes
Labelling area	Without
Material	Polyamide
Max. Bundle diameter	55 mm
MIL approval	no
Mounting temperature, max.	90 °C
Mounting temperature_min.	-30 °C
Permitted temperature range, max.	90 °C

Permitted temperature range, min.	-30 °C
Reflective	no
Releasable lock	no
Strip closure	Plastic tongue/tab
Tensile strength	80 N
Transparent	no
UL approval	yes
UV-resistant	yes
Version for	Externally toothed
VG approval	no

All types

Types	Length	Max. Bundle diameter	Colour	Item no.	Quantity	SSU
565 2.5x75 SWUV	75 mm	15 mm	Black	2331802	piece	100 piece
565 2.5x100 SWUV	100 mm	22 mm	Black	2331812	piece	100 piece
565 2.5x150 SWUV	150 mm	39 mm	Black	2331818	piece	100 piece
565 2.5x200 SWUV	200 mm	55 mm	Black	2331824	piece	100 piece
565 3.6x150 SWUV	150 mm	36 mm	Black	2331832	piece	100 piece
565 3.6x200 SWUV	200 mm	52 mm	Black	2331838	piece	100 piece
565 3.6x290 SWUV	290 mm	82 mm	Black	2331844	piece	100 piece
565 3.6x365 SWUV	365 mm	105 mm	Black	2331850	piece	100 piece
565 4.8x120 SWUV	120 mm	27 mm	Black	2331862	piece	100 piece
565 4.8x160 SWUV	160 mm	39 mm	Black	2331868	piece	100 piece
565 4.8x200 SWUV	200 mm	52 mm	Black	2331874	piece	100 piece
565 4.8x300 SWUV	300 mm	83 mm	Black	2331880	piece	100 piece
565 4.8x365 SWUV	365 mm	105 mm	Black	2331886	piece	100 piece
565 4.8x430 SWUV	430 mm	125 mm	Black	2331892	piece	100 piece
565 7.6x200 SWUV	200 mm	52 mm	Black	2331912	piece	100 piece
565 7.6x300 SWUV	300 mm	80 mm	Black	2331918	piece	100 piece
565 7.6x380 SWUV	380 mm	105 mm	Black	2331924	piece	100 piece
565 7.6x450 SWUV	450 mm	128 mm	Black	2331936	piece	100 piece
565 9x760 SWUV	760 mm	227 mm	Black	2331946	piece	100 piece
