Cable ladder with trapezoidal rungs, standard FT 3000 | 200 | 5 | no

Cable ladder with trapezoidal rungs, standard FT

Item no. 7097425 | EAN 4012196980369

Item no. / Types

Length	3000 mm

Width

Rail thickness	5 mm

Maintain electrical functions	no

Product description

Product description

Shipbuilding cable ladder with perforated side rail of side height 40 mm with welded, perforated trapezoidal rungs which open in a downwards direction. Load tested according to IEC in conjunction with connector, type SLV.

Technical data

Technical data

Colour	zinc
CO₂ Footprint (GWP) Cradle-to-Gate	8,029 kg CO₂e / 1 Meter
Dimension	40x210x3000
Dimension B	210 mm
Fastening of rung	Welded
Height	40 mm
Length	3000 mm
Length	3000 ft
Maintain electrical functions	no
Material	Steel
Rail thickness	5 mm
Rung distance	300 mm

Rustproof steel, pickled	no
Side perforation	yes
Side rail version	Flat profile
Support spacing 1.5 m	3 kN/m
Support spacing 2.0 m	2 kN/m
Support spacing 2.5 m	1 kN/m
Support spacing 3.0 m	0,6 kN/m
Surface	Hot-dip galvanised
Version of the rungs	Profile perforated
Wide-span version	no
Width	200 mm

Technical data

Load diagram, cable ladder, type SL62

Permitted cable tray/ladder load in kN/m without man load
Support width in m
Rail bend in mm at permitted kN/m
Load curve with cable tray/ladder width in mm
Strut bend curve according to support width
Load scheme during testing

All types

All types

Types	Length	Width	Rail thickness	Maintain electrical functions	Item no.	Quantity	SSU
SL 62 100 FT	3000 mm	100 mm	5 mm	no	7097409	m	3 m
SL 62 150 FT	3000 mm	150 mm	5 mm	no	7097417	m	3 m
SL 62 200 FT	3000 mm	200 mm	5 mm	no	7097425	m	3 m
SL 62 300 FT	3000 mm	300 mm	5 mm	no	7097433	m	3 m
SL 62 400 FT	3000 mm	400 mm	5 mm	no	7097441	m	3 m
SL 62 500 FT	3000 mm	500 mm	5 mm	no	7097468	m	3 m
SL 62 600 FT	3000 mm	600 mm	5 mm	no	7097476	m	3 m
