- Product description
-
Product description
Shipbuilding cable ladder with perforated side rail of side height 40 mm with welded, perforated trapezoidal rungs which open in a downwards direction.
-
- Technical data
-
Technical data
Dimension 40x510x3000 Fastening of rung Welded Maintain electrical functions no Material Aluminium Rail thickness 5 mm Rung distance 300 mm Rustproof steel, pickled no Side perforation yes Side rail version Flat profile Surface Pickled Version of the rungs Profile perforated Wide-span version no Dimensions
Dimension B 510 mm Height 40 mm Length 3000 ft Length 3000 mm Width 500 mm Loads
Support spacing 1.5 m 1,4 kN/m Support spacing 2.0 m 0,65 kN/m Support spacing 2.5 m 0,35 kN/m Support spacing 3.0 m 0,2 kN/m Technical data
Load diagram, cable ladder, type SL62 ALU
-
Permitted cable tray/ladder load in kN/m without man load
-
Support width in m
-
Rail bend in mm at permitted kN/m
-
Load scheme during testing
-
Load curve with cable tray/ladder width in mm
-
Strut bend curve according to support width
-
- All types
-
All types
- Downloads
-
Data sheet SL 62 500 ALU / 7099760 , 0.24MB , pdfCatalogue Kabeltragsysteme , 45.23MB , pdfDeclaration of conformity SL 62 500 ALU / 7099760 , 0.15MB , pdf
