Adjustable connector FS

Item no. 6091318 | EAN 4012196299294

6091318 / WRGV 110 FS
110 mm
2.5 mm
Product description

Product description

Adjustable connector for wide span cable trays and ladders with a side height of 110 mm.
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • Wide span cable tray, side height, 110 mm
  • Wide span cable ladder, side height 110 mm
Technical data

Technical data

Adjustable connector, horizontal no
Articulated connector, vertical yes
Connection type Screw connector
Dimension 110x380
Maintain electrical functions no
Material Steel
Plate thickness 2,5 mm
Rustproof steel, pickled no
Suitable for cable ladder yes
Suitable for cable tray yes
Suitable for cable tray system height 110 mm
Suitable for mesh cable tray no
Surface Strip galvanized
Version for Straight connector

Dimensions

Height 110 mm
Length 380 mm
Width 20 mm
All types

All types

Types Height Plate thickness Item no. Quantity SSU
WRGV 110 FS 110 mm 2.5 mm 6091318
2 piece
Downloads

Download

Declaration of conformity WRGV 110 FS / 6091318 , 0.15MB , pdf
Download

WRGV 110 FS / 6091318
Download
